Ring space seal Curaflex Nova<SUP><SUB>®</SUB></SUP> Uno/wide - PIPLDTHRGH-RGSEAL-CORPIP-SST-HP-D200

Ring space seal Curaflex Nova® Uno/wide

Ring space seal HP stainless steel corrugated pipe
PIPLDTHRGH-RGSEAL-CORPIP-SST-HP-D200

Art.-no. 0886610102

EAN 4099618254758

All versions

-,--
price per selected packing unit | Individual prices for customers after login
Ring space seal Curaflex Nova® Uno/wide

Art.-no. 0886610102

-,--
price per selected packing unit
Quantity
PU
x 1 pcs

Show availability in Würth shop
Exclusively for trade customers

Register now and access more than 125,000 products

Report incorrect product information here

Gas-tight, radon-proof and water-pressure-tight wall duct for core holes in concrete or liner/fibre cement pipes for stainless steel heat pump pipe
  • Water-pressure-tight, gas-tight and radon-proof

  • Nuts with integrated torque (ITL system) always produce the optimal contact pressure for 100 % sealing; can also be installed with cordless screwdriver

  • Wide rubber seal covers the pre-fabricated concrete shell and concrete core

  • Permanent sealing without retensioning (maintenance-free)

  • Fixing tabs for clear positioning (included in scope of delivery)
Product information

Würth Catalogue

Datasheets(X)

Certificates/ Documents

 |

 |

Suitable for pipe diameter

200 mm

Suitable for core-drilled holes/pipe linings

250 mm

Max. pressure

0.5 bar

Material of profile

Fibre glass reinforced plastic

Material of screw

Stainless steel A4

Material of rubber profile

EPDM

Width

154 mm

Sealing width

80 mm

Diameter

254 mm

Shore A hardness

50

Colour

Black, Blue
