WingLine S folding door fittings with automatic closing
For detailed information, other images and documents, please select individual articles from the following table.
WingLine S folding door fittings with automatic closing
Designed without lower guide especially for smaller fronts up to a height of max. 1000 mm
- Material of door: Wood
- Installation option: Overlay
- Type of assembly: Mounting on cabinet side panel
- Suitable for max. door weight: 5 kg
- Suitable for number of doors: 2
- Suitable for min. door thickness: 16 mm
- Suitable for max. door thickness: 22 mm
- Suitable for min./max. door thickness: 16-22 mm
- Suitable for min. door width: 250 mm
- Suitable for max. door width: 450 mm
- Suitable for min./max. door width: 250-450 mm
- Suitable for max. door height: 1000 mm
- show more ... show less ...
Exclusively for trade customers
Register now and access more than 125,000 products
Variants
- A conventional hinged door cabinet can be easily upgraded into a folding door cabinet with the folding door fittings
- Thanks to the optional pull-to-move-silent unit, the doors open automatically (from an opening angle of 35°) and close softly
- Damped opening and silent closing. Even greater convenience for WingLine S with pull-to-move unit
- The hinges of the guide parts feature automatic closing
- Available in three different colours to ensure seamless integration into the cabinet design
- Intelligent mounting accessories mean assembly can be carried out by just one person
Dimensions subject to change. Subject to technical changes.
Application area
Wardrobes, closets
Instructions
For recessed installation, screw on the door leaf.
